Wheels Chart
Now available as free Android app:
Show in the list:
Move your cursor over any item to see subparts: rim and tire (does not apply to single-piece wheels). When subparts are shown, move your cursor over a rim to see the tires it fits, or over a tire to see the rims it fits. Click any image to open respective Bricklink's catalog page in a new tab in your browser
You can sort the chart by clicking fields from 'Total diameter' to 'Weight'. Click a field again to toggle between ascending and descending sorting.
You can sort the chart by clicking fields from 'Total diameter' to 'Weight'. Click a field again to toggle between ascending and descending sorting.
| Wheel: | Total diameter: | Tire width: | Rim diameter: | Rim width: | Weight: | Rarity: |
|---|---|---|---|---|---|---|

|
14 mm | 6 mm | 11 mm | 8 mm | 0.75g | common |
   |
14 mm | 7 mm | 7 mm | 4 mm | 0.5g | uncommon |
|
17 mm | 6 mm | 11 mm | 8 mm | 1.1g | common |
 |
20 mm | no tire | 20 mm | ? | 3g | common |
 |
23 mm | no tire | 23 mm | 23 mm | 4g | common |

|
24 mm | 13.5 mm | 17.5 mm | 16 mm | 3g | common |

|
24 mm | 7 mm | 17 mm | 7 mm | 3g | common |

|
30 mm | 3 mm | 24 mm | 3 mm | 2g | common |
|
30 mm | 10 mm | 17 mm | 7 mm | 6g | common |

|
30 mm | 14 mm | 17.5 mm | 16 mm | 9g | common |
|
30 mm | 14 mm | 17.5 mm | 16 mm | 9g | common |
|
30.4 mm | 14 mm | 17.5 mm | 16 mm | 8g | common |

|
30.5 mm | 14 mm | 24 mm | 14 mm | 6g | common |

|
37 mm | 21 mm | 30 mm | 20 mm | 10g | common |

|
42 mm | 13 mm | 30 mm | 13 mm | 14g | common |
 |
42.5 mm | no tire | 42.5 mm | 27.5 mm | 12g | uncommon |
|
43 mm | 26 mm | 30 mm | 20 mm | 13g | common |

|
43 mm | 28 mm | 30 mm | 22.5 mm | 18g | common |

|
43.2 mm | 14 mm | 30 mm | 14 mm | 13g | uncommon |
|
43.2 mm | 21 mm | 30 mm | 20 mm | 15g | common |
|
43.2 mm | 13 mm | 30.5 mm | 14 mm | 18g | common |

|
43.2 mm | 22 mm | 30.4 mm | 20 mm | 17.5g | uncommon |

|
49 mm | 19 mm | 30.5 mm | 19 mm | 17g | uncommon |
|
49.5 mm | 20 mm | 30 mm | 20 mm | 17g | common |

|
49.5 mm | 20 mm | 30.4 mm | 20 mm | 16g | rare |
|
56 mm | 24 mm | 30 mm | 20 mm | 18g | common |

|
56 mm | 28 mm | 43 mm | 26 mm | 23g | uncommon |
|
56 mm | 26 mm | 30.4 mm | 20 mm | 18g | rare |

|
62.4 mm | 20 mm | 43 mm | 17.5 mm | 46g | uncommon |
|
63 mm | 19 mm | 30 mm | 19 mm | 27g | uncommon |

|
67 mm | 14 mm | 58.5 mm | 14 mm | 25g | rare |

|
67 mm | 27.5 mm | 58.5 mm | 27.5 mm | 33g | uncommon |

|
68.7 mm | 27 mm | 43.2 mm | 26 mm | 31g | rare |
|
68.7 mm | 33 mm | 43 mm | 26 mm | 30g | uncommon |
 |
68.8 mm | no tire | 68.8 mm | 35 mm | 18g | rare |

|
68.8 mm | 36 mm | 56 mm | 34 mm | 39g | common |
|
68.8 mm | 36 mm | 43 mm | 34 mm | 35g | uncommon |
|
68.8 mm | 39 mm | 43 mm | 30 mm | 59g | uncommon |

|
68.8 mm | 36 mm | 56 mm | 34 mm | 39g | rare |
 |
71 mm | no tire | 71 mm | 46 mm | 37g | rare |
|
75.1 mm | 28 mm | 43.2 mm | 26 mm | 28g | rare |

|
81.6 mm | 13.6 mm | 61.6 mm | 13.6 mm | 32g | rare |
|
81.6 mm | 13.6 mm | 61.6 mm | 13.6 mm | 30g | common |

|
81.6 mm | 44 mm | 61.6 mm | 42 mm | 58g | rare |

|
81.6 mm | 44 mm | 62.3 mm | 42 mm | 57g | rare |
|
81.6 mm | 42 mm | 56 mm | 26 mm | 47g | uncommon |
|
81.6 mm | 37 mm | 43 mm | 26 mm | 41g | uncommon |
|
81.6 mm | 36 mm | 56 mm | 34 mm | 51g | rare |

|
81.6 mm | 33 mm | 68 mm | 29.5 mm | 55g | rare |

|
81.6 mm | 49 mm | 62 mm | 45 mm | 88g | rare |
|
81.6 mm | 36 mm | 56 mm | 34 mm | 51g | rare |

|
81.6 mm | 44 mm | 62.3 mm | 42 mm | 57g | rare |

|
82 mm | 23 mm | 43 mm | 23 mm | 53g | uncommon |

|
82 mm | 33 mm | 62 mm | 31 mm | 69g | rare |

|
92 mm | 20 mm | 74.5 mm | 20 mm | 54g | rare |
|
92 mm | 27 mm | 74.5 mm | 20 mm | 63g | rare |

|
94.2 mm | 20 mm | 75 mm | 17 mm | 36g | uncommon |

|
94.2 mm | 22 mm | 75 mm | 15.8 mm | 35g | rare |
|
94.3 mm | 38 mm | 75 mm | 31.6 mm | 59g | rare |
|
94.3 mm | 37 mm | 56 mm | 34 mm | 67g | uncommon |
|
94.8 mm | 42 mm | 56 mm | 34 mm | 58g | uncommon |
|
100.6 mm | 18 mm | 75 mm | 17 mm | 40g | uncommon |
|
105 mm | 60 mm | 62 mm | 45 mm | 188g | rare |
|
107 mm | 44 mm | 56 mm | 34 mm | 81g | uncommon |
 |
156 mm | no tire | 156 mm | 27 mm | 55g | rare |
 |
212 mm | no tire | 212 mm | 21 mm | 84g | rare |
